Industrial facilities depend on stable, controlled, and protected electrical distribution to maintain production, safety, and operational continuity. As factories become more automated and energy-intensive, selecting the right medium voltage switchboard has become an important engineering decision.

Medium voltage switchboards manage, protect, and distribute electrical power across industrial networks. They are commonly used for incoming power supply, transformer feeders, motor feeders, capacitor banks, and other critical electrical loads. The right configuration can improve operational safety, simplify maintenance, support future expansion, and integrate with modern automation systems.

For industrial businesses working with EPC contractors, electrical consultants, and equipment manufacturers, the selection process should go beyond voltage ratings. Factors such as load requirements, fault levels, protection, space, environmental conditions, automation, safety standards, and future capacity should all be evaluated.

What Is a Medium Voltage Switchboard?

A medium voltage switchboard is an electrical distribution assembly designed to control and protect circuits operating at medium voltage levels. Depending on the application and equipment design, industrial facilities may use systems within the 11kV to 33kV range.

A typical switchboard can include circuit breakers, busbars, protection relays, current transformers, voltage transformers, metering equipment, isolators, and control components.

Modern medium voltage panel solutions may also incorporate draw-out breakers and instrument transformers to support safer operation and easier maintenance. Hartek's current product range includes 11kV–33kV medium voltage panels, with product specifications covering 12kV/36kV operational voltage and multiple current ratings.

1. Evaluate the Facility's Electrical Load

The first step in selecting an MV switchboard is to understand the facility's present and expected electrical load.

Industrial plants can have different types of loads, including:

• Large motors
• Transformers
• HVAC systems
• Production machinery
• Pumps and compressors
• Capacitor banks
• Renewable energy systems
• Data and automation equipment

The switchboard should have adequate rated current capacity for the connected load while allowing reasonable scope for future expansion.

Engineers should assess maximum demand, load diversity, motor starting requirements, power factor, and expected future capacity before finalising the switchboard configuration.

2. Check Voltage, Short-Circuit and Protection Requirements

Voltage rating alone does not determine whether a switchboard is suitable. Short-circuit withstand capacity and protection coordination are equally important.

Industrial facilities can experience faults such as:

• Short circuits
• Earth faults
• Overcurrent conditions
• Equipment insulation failures
• Busbar faults

The selected switchboard should therefore match the site's prospective short-circuit level and protection philosophy.

Protection relays and circuit breakers must work together so that a fault can be isolated without unnecessarily disconnecting healthy sections of the plant.

This is also where a relay control panel or control and relay panel can complement the MV distribution system by providing monitoring, protection, control, and communication functions.

For larger substations, a control and relay panel in substation may interface with protection devices, breakers, transformers, meters, and automation systems. Hartek manufactures control relay panels up to 220kV as part of its Power Distribution Products portfolio.

3. Select the Appropriate Switchgear Configuration

Industrial applications can require different switchgear arrangements depending on available space, maintenance philosophy, safety requirements, and operational continuity.

Key factors include:

Air-Insulated Switchgear

Air-insulated systems are widely used for industrial distribution applications and can offer practical maintenance access and configuration flexibility.

Draw-Out Design

Draw-out breakers can make inspection, maintenance, and replacement easier because the breaker can be withdrawn from its service position.

Fixed-Mounted Configuration

Fixed-mounted equipment may be suitable for applications where equipment arrangement, maintenance requirements, and available space support a simpler configuration.

The correct choice should be based on the facility's electrical design, operating environment, maintenance strategy, and project specifications rather than simply selecting the most feature-rich option.

4. Consider Space and Installation Conditions

Industrial plants often have limited electrical-room space. Equipment dimensions, cable-entry requirements, ventilation, access clearances, and future expansion should therefore be considered before ordering the switchboard.

Environmental conditions also matter.

Facilities may operate in areas exposed to:

• Dust
• Moisture
• High temperatures
• Chemicals
• Corrosive environments
• Outdoor conditions

The enclosure, ingress protection, insulation arrangement, and material selection should match the installation environment.

Where space is particularly constrained, a packaged transformer substation can combine MV switchgear, a distribution transformer, and an LV switchboard within a compact enclosure. Hartek's packaged substation solutions cover 12kV–36kV applications and can accommodate oil or dry-type transformers up to 3 MVA.

5. Plan for Automation and SCADA Integration

Modern industrial facilities increasingly require real-time visibility into their electrical networks. A switchboard should therefore be evaluated not only as a power distribution asset but also as part of the plant's automation architecture.

Integration with a scada system in power system applications can provide information related to voltage, current, power, breaker status, alarms, and equipment conditions.

A properly configured scada control system can help operators monitor electrical assets from a central interface and respond faster to abnormal operating conditions.

A scada based system can also support remote operation and data acquisition, depending on the plant's automation architecture.

For larger industrial networks and substations, scada in power systems can connect field devices, protection equipment, meters, RTUs, PLCs, and control interfaces to provide a more coordinated operating environment.

Hartek's Power Distribution Products portfolio includes SCADA & Automation alongside MV switchboards, LV switchboards, control relay panels, busbar trunking, and packaged substations.

6. Check Standards, Testing and Certification

Safety and compliance should remain central to the procurement decision.

Industrial buyers should verify applicable standards, type-test requirements, routine testing procedures, protection-system testing, and project-specific specifications before finalising a supplier.

Hartek's MV switchboard product information references IEC 62271-200:2011 and highlights applications including potential transformer, capacitor, and motor feeders.

The buyer should also evaluate the manufacturer's engineering capability, testing infrastructure, documentation, commissioning support, and after-sales service.

7. Evaluate the Manufacturer's Engineering Capability

Choosing the right manufacturer is as important as choosing the technical configuration.

Industrial customers should consider:

• Manufacturing capability
• Design and engineering expertise
• Customisation capability
• Testing facilities
• Quality management systems
• Project execution experience
• Installation and commissioning support
• Spare parts and service availability

This becomes particularly important when MV switchboards are part of a larger electrical infrastructure project involving transformers, substations, renewable generation, SCADA, and LV distribution.

For businesses comparing epc companies in india, the ability to coordinate engineering, procurement, equipment supply, installation, testing, and commissioning can simplify project execution.

Similarly, top epc companies in india increasingly need integrated electrical distribution capabilities to support industrial and infrastructure projects.

MV Switchboards in Renewable and Hybrid Industrial Systems

Industrial electrical systems are also changing as businesses adopt rooftop solar, captive renewable energy, battery storage, and other distributed energy resources.

This creates additional requirements for protection, metering, synchronization, power-flow management, and grid interaction.

For solar epc companies, the MV switchboard can become an important part of the electrical evacuation and grid-interconnection system. The same applies to epc solar companies working on industrial and utility-scale projects.

Companies evaluating top solar epc companies in india or solar epc companies should therefore assess whether the EPC partner can coordinate generation, evacuation, protection, and distribution requirements.

For larger substations, associated equipment may include a 132 kv control relay panel, transformers, protection systems, and SCADA interfaces.

Where LV Systems Fit Into the Overall Architecture

An industrial facility rarely depends on MV equipment alone. Power typically moves through a coordinated MV-to-LV distribution architecture.

After voltage transformation, LV switchboards distribute power to individual plant loads and equipment.

When evaluating low voltage switchboard manufacturers, buyers should assess how well their LV equipment integrates with the upstream MV system.

An lv switchgear panel should have appropriate ratings, protection coordination, busbar capacity, and outgoing feeder arrangements for the connected loads.

This integrated approach helps prevent compatibility issues between MV switchgear, transformers, LV panels, protection systems, and automation equipment.

Key Factors to Compare Before Selecting an MV Switchboard

Before placing an order, industrial buyers should compare suppliers against the following checklist:

Build a Smarter Industrial Power Distribution System

Selecting a medium voltage switchboard requires a balance of electrical performance, protection, safety, maintainability, automation, space, and future expansion. The right solution should fit the facility's operating conditions and integrate effectively with transformers, LV distribution, control systems, and SCADA.

Hartek's Power Distribution Products division manufactures 11kV and 33kV medium voltage switchboards alongside LV switchboards, control relay panels, busbar trunking, SCADA & Automation, and packaged substations. Its portfolio serves industrial, utility, building, and renewable-energy applications.

For organisations planning new industrial facilities or upgrading existing electrical infrastructure, selecting an experienced engineering and manufacturing partner can support better coordination from system design through equipment supply and commissioning.

Frequently Asked Questions

1. What is a medium voltage switchboard used for?

A medium voltage switchboard controls, protects, and distributes electrical power within industrial facilities, substations, utility networks, and other electrical installations.

2. What voltage levels are commonly used in industrial MV switchboards?

Industrial applications commonly use MV systems such as 11kV and 33kV, depending on the facility's electrical network and utility requirements.

3. What factors should be considered when selecting an MV switchboard?

Key factors include voltage, current, short-circuit rating, protection, installation environment, space, automation requirements, applicable standards, maintenance needs, and future expansion.

4. Can an MV switchboard be integrated with SCADA?

Yes. MV switchboards can be integrated with SCADA and automation systems to support monitoring, alarms, data acquisition, and remote control, depending on the overall system architecture.

5. Why is protection coordination important in industrial power systems?

Protection coordination helps ensure that faults are isolated selectively, reducing unnecessary interruptions and helping protect electrical equipment and personnel.
